Specifications & Parameters
Model | EF2513-R5(belt) | EF2513-R5(belt) | EFM2513-R6 (magnetic levitation) | EFM2513-K (magnetic levitation) | EFM3020 (Magnetic levitation & heightening) | |
Maximum Print Width | 250cm*130cm | 250cm*130cm | 250cm*130cm | 250cm*130cm | 300cm*200cm | |
Medium Thickness | 100mm | 100mm | 100mm | 100mm | 100mm | |
Print Head | Ricoh G5 Printhead | I3200-U1 Printhead | Ricoh G6 Printhead | Konica 1024i Printhead | Konica 1024i Printhead | |
Print Speed | 3-8pcs 15-60m²/h | 1-8pcs 15-150m²/h | 3-8pcs 18-72m²/h | 4-16pcs 33-180m²/h | 4-16pcs 35-188m²/h | |
Sort |
It can print almost any plane, three-dimensional, concave and convex soft and hard materials, for example: acrylic board, metal plate, glass, wood plate, ceramic floor, cardboard, plastic leather, textile cloth, wallpaper, PC/PE/PVC | |||||
Power | AC220/110±10,50HZ~60HZ，4500W/6000W | |||||
Printer Packing Size | (EF2513)L4100mm*W2060mm*H1400mm L4360mm*W2120mm*H1610mm | (EFMG3020)L4600mm*W2688mm*H1450mm L4910mm*W3288mm*H1660mm | ||||
Net Gloss Weight | 1550kg/1670kg | 1760kg/2050kg | ||||
Product Features:
1. Equip with 3-16 pcs Ricoh G5/ Ricoh G6/ Konica 1024i and other industrial grade high-precision & high-speed printhead;
2. lmported THK silent linear guide rail and slider,imported screw and servo motor;
3. Automatic high precision height measuring device, sprinkler head bilateral anti-collision device;
4. One-button automatic positioning function, when printing large size plate, it is more convenient and easy to operate by one person;
5. 45 printing platform support points, when using bidirectional mode printing small products, the pattern accuracy is consistent;
6. High power electrostatic eliminator, effectively eliminate static electricity on the medium, eliminates static electricity caused by flying ink ,pattern is not clear phenomenon;
7. sprinkler head automatic flash spraying function, in standby state, the nozzle will be 2 hours interval automatic micro flash spraying once, to avoid the nozzle drying;
8. Secondary cartridge constant temperature heating function, white ink inner circulation function, prevent white ink precipitation, improve ink fluency, reduce the probability of plugging;
9. Automatic ink channel valve switch, power off automatically close the ink channel, prevent air from entering from the nozzle, without manual, convenient and fast;
10. 3.4.5KW high power strong turbine suction fan, equipped with silencer, really achieve the perfect effect of strong force and low sound.
Use cases
