Specifications & Parameters
Machine model | FRM3300 | ||
Printing size | 3200mm | ||
Number of printheads | Konica 1024i /Ricoh Gen6(4~12) | ||
Four-row nozzle printing speed | External light mode | Internal light mode | Color White Color |
150-200 m²/h | 100-150 m²/h | 45-90 m²/h | |
Printable materials | Soft film/printing cloth/knife scraping cloth/lamp piece/transparent electrostatic film/canvas/leather/textile material (almost any soft material) | ||
Power requirements | AC220±10,50HZ~60HZ/5200W | ||
Print interface | High-speed USB transmission interface | ||
Driver software | Win7/Win8/Win10 X64 | ||
Working environment | Temperature: 20℃~30℃, humidity: 35%RH~65%RH | ||
Equipment size | L6230mm*W1660mm*H2080 | ||
Packing size | L6280mm*W1710mm*H2110 | ||
Equipment net weight | 3800kg | ||
Equipment gross weight | 4050kg | ||
Product Features:
1. Printing width 3.2m, equipped with 8-32 Ricoh G6/Konica 1024i print heads, variable ink drop technology
2. Magnetic suspension linear motor/metal grating imported from Japan, high precision, high speed, long life, low maintenance cost
3. Dual linear high-precision silent guide rails + dual servo AC motors imported from Japan, high precision, good silent effect, higher definition, longer equipment life;
4. Shanghai Rongyue board top control system, German imported drag chain, Korean imported LG LED-UV curing lamp beads
5. European imported color management software, print head aging color compensation function, ink saving/intelligent typesetting function, higher color reproduction (four-color reproduction of pure "gold/silver")
6. Multi-function printing mode, in addition to roll/plate dual use, can also single row 7 color matching, meet the multi-function printing mode, truly one machine with multiple functions
7. Fully automatic ink path system, white ink internal circulation and automatic flash spray function, monochrome positive pressure ink supply, greatly reducing the risk of clogging
