Specifications & Parameters
Model | M-1804 High Speed Inkjet Printer | |||
Maximum Print Width | 1800mm | |||
Head Number | 4pcs | |||
Card system | Shenzhen Hoson/ Beijing BYHX | |||
Print head type | I3200 | DX5/DX7 | 4720 | |
Printing speed | 3 PASS | 108 m²/h | 82 m²/h | 118 m²/h |
4 PASS | 80 m²/h | 65 m²/h | 82 m²/h | |
6 PASS | 60 m²/h | 46 m²/h | 60 m²/h | |
Ink | Type | Weak solvent/water-based/thermal transfer ink | ||
Color | CMYK | |||
Material type | PP/adhesive/photo paper/car sticker/one-way sticker/light film | |||
Ink supply | Automatic continuous supply system | |||
Print head maintenance | One-button automatic nozzle cleaning system | |||
RIP software | Maintech 6.0 (standard)/Photoprint (optional) | |||
Data interface | Gigabit network card transmission | |||
Auxiliary system | Material collection and release system | Automatic damping paper collection device/double damping paper release device | ||
Print head height | Adjustable 2-5mm from the printing platform | |||
Equipment-related information | Working voltage | AC220V 50/60Hz | ||
Power supply | 3500W | |||
Working environment | Working temperature: 22-28℃ Humidity: 40%-60% | |||
Machine size | L3220mm*W920mm*H1540mm | |||
Packing size | L3650mm*W840mm*H800mm | |||
Product features:
1. Printing width 1.8 meters, can be equipped with 2 Epson I3200/DX5/DX7/4720 print heads
2. Top BYHX board control system, THK silent guide rails and sliders, Leadshine servo motor
3. Print head anti-collision protection system, paper shortage emergency stop device
4. Adjustable suction platform, infrared drying device
5. High-power dual-motor material collection device
6. High-precision all-aluminum ink-absorbing stack, main beam, and platform are all CNC high-precision processed
7. Water ripple sprayed sheet metal, showing the high-end and gorgeous appearance
