Product Features:
1. Equipped with beveled racks and belts, it adapts to various processing needs.
2. Imported linear guides and high-speed stepper motors and drivers ensure smooth, ripple-free cutting edges.
3. The integrated frame structure resists wear and ensures stable and quiet operation. The specially treated, fully open work platform provides easy operation.
4. DSP system and open software interface are compatible with vector design software such as AutoCAD, CorelDRAW, Wentai Engraving, and Photoshop.
5. Unique top and bottom exhaust and dust removal system protects marking materials with airflow.
Applicable Materials:
Acrylic, wood, bamboo, fabric, marble, plexiglass, crystal, plastic, clothing, paper, leather, rubber, printing blocks, ceramics, and other non-metallic materials.
Specifications and parameters:
Models | CM1318 | CM1325 | CM1625 |
Working Area (mm) | 1300 X 1800 | 1300 X 2500 | 1600 X 2500 |
Laser Power | 80W/100W/130W/150W/180W | ||
Laser Tube | Sealed CO2 laser tube | ||
Cooling | CW-3000/CW-5000/CW-5200 water chiller | ||
Working platform | Blade platform | ||
Drive | Tepper Motor | ||
Engraving Speed | 0-1000mm/s | ||
Cutting Speed | 0-600mm/s | ||
Positioning Accuracy | <0.01mm | ||
Resolution | 2500DPI | ||
Supported Software | ArtCut, PhotoShop, CoreDraw, AutoCAD | ||
Supported File Types | PLT, DXF, BMP, AI, DST | ||
Interface | USB/Ethernet | ||
Operating Voltage | 220V/50-60HZ | ||
Working Environment | Temperature: 0°C-45°C, Humidity: 5%-95% | ||
Dimensions (mm) | 2930 X 2000 X 1058 | 3630 X 2000 X 1058 | 3630 X 2260 X 1058 |
Gross Weight (kg) | 800 | 900 | 980 |
