Ricoh TH6310F Printhead, 1 color, 5PL

Ricoh TH6310F Printhead, 1 color, 5PL

• Product name:13200(8)-A1H
• Ink type: Aqueous
• Type: PrecisionCoreMicroTFP Printhead
• Width x Depth x Height: 2.7 x2.3 x1.4 inch (69.1x59.5x36.7mm)
• Weight: 82g
• Number of nozzle: 32600
• Nozzle pitch /nozzle row: 1/300 inch
• Nozzle rows: 8 rows
• Nozzle Resolution: 300 npi/row 600npi/2 rows1,200npi/4 rows
• Max. number of color inks: 8 colors
• Effective print width: 1.33 inches (33.8 mm)
• Viscosity range: 3-4mPa.s
• Positioning Mechanism: Reference hole
• $2,954.00 - 3,050.00
